Filter Cloth for Various Kind of Filter Press and Vacuum Filter with Polypropylene Monofilament
Basic Info.
| Model NO. | PPMO |
| Anti Alkaline | Good |
| Size | Customerzied |
| Working Temperature | 130 |
| Anti Acidic | Good |
| Transport Package | Standard Export Packing |
| Specification | MONO |
| Trademark | RQ |
| Origin | China |
| HS Code | 5911900 |
| Production Capacity | 5000PCS / Week |
Product Description
1.Our products including monofilament, multifilament, mixed mono-multifilament, mixed multifilament-staple fibres, and other innovative products, are especially dedicated to filter press machines.
2.Our range is able to cover all chemical requirements, with polymers such as Polypropylene (PP), Polyamide (PA, Nylon, Rilsan, PA6-6, PA 6, PA 6-10, PA11, PA12), Polyester (PET) or PBT etc.
3.All the media are calendered to provide the smooth surface needed for a good cake release
4.All the media are properly thermo-fixed to ensure the dimensional stability.
5.Filter press cloth use for different size filter press filter plates,such as 400*400mm,500*500mm,630*630mm,800*800mm,1000*1000mm,1200*1200mm,1250*1250mm, 1300*1300mm,1500*1500mm,1600*1600mm,2000*2000mm etc. also we offer special OEM service for filter cloth users or special size from filter press users.
6. We also offer gasketed type filter press plate cloth,with high quality gaskets with high quality filter cloth to make sure all the filter press will work in top efficiency.
7.Our filter cloths are adapted to the different needs of the customers, like plate dimension, cake weight, particle retention or productivity. Our has developed a wide range of standard and specific designs, making up options for fixations, barrel and rubber neck, or sealing.
| Item | Date |
| filter press cloth material | PP, PE, PA, Nylon,PET etc. |
| filter press cloth with filter plate size | 150mm,250mm,400m,470m,500m,630mm,650mm,8000mm,870mm,1000mm,1080mm,1200mm,1250mm,1300mm,1500mm,1600mm,1800mm,2000mm,2100mm,2000*1500mm, 2000*1800mm etc. All the size will be according to Filter press |
| Filter press plate type | chamber filter plate,recessed chamber filter plate,membrane filter plate,membrane and recessed plate mixed type and chamber membrane filter plate mixed operation etc. |
| Filter press cloth gasket material | NR, NBR, EPDM, FDM etc. |
| Filter press cloth Weave | Twill, Plain etc. |
| Filter press cloth Warp | monofilament, multifilament, mixed mono-multifilament, mixed multifilament-staple fibres, and other innovative productsSmall Filter Press Filter pressure |
| Filter press cloth Finish | Heat set & Calendered |
| Filter press cloth air permeability | 0-1500 L/m2.S |
| Food | Environment | Chemical | Mineral |
| Sugar, Cacao, Carrageenan (Algae), Bean protein, Beer, Juice, Enzyme, Pectin, Starch and gluten, Wine, Rice bran oil, Palm oil, Colza oil | Potable Water, Urban Waste Water Treatment, Industrial Waste Water Treatment, Galvanic Treatment, Automotive Cataphoresis, Metallic residue | Polymers, Resin and Terpen derivatives, Naphtalenesulfonate, Precipited Silicate, Colours, Pigments, Fertilizers | Alumina red mud management, cement, chalk, coal, concentrates & tailings (copper, gold, iron, silver, zinc, etc) gravel, gypsum, kaolin & clay, lithium, rare earths (cobalt, bismuth, uranium, etc.) titanium dioxide and many more |
Industrial Filter Fabric/ polyester polypropylene micron Filter Press Filter Cloth bag
Industrial Filter Fabric Filter Press Filter Cloth is mainly applied to filter press, including chamber filter press, Belt filter press , membrane filter press, recessed, plate and frame filter press , Disc Filter Machie , etc.
Our specilized filter cloth , non woven needle felt is specially developed for the metal concentration filter press processing , with fine filter precision , etc.
With over decades manufacturing and researching experience , we have supplied filter cloth for various industry including mining industry , chemical industry , waste water treatment , food industry , etc .
Filter Cloth Micron Rating : 1- 150 Micon , Full range mesh / micron .
Filter Cloth : Polypropylene Filter Cloth , Nylon 66 Filter Cloth , Polyester Filter Cloth , Cotton Filter Cloth , PVC Filter Fabrics .
Filter Press Machine : filter cloth work for Chamber Filter Press , Plate Filter Press , Disc Filter system , Belt Filter Press , Belt Squeez press filter , etc.
Filter Press Cloth Application :
Mining Mineral Industry :
Mineral Concentration , metal concentration , Tailing Mine Treatment , Coal Concentration ,
Mining of Gold , Copper , Zinc , Nickel , Iron ,
Red mud, potash fertilizer, vanadium ore, the end of coal, clean coal, clay, Kaolin clay, etc.
Metal Concentration :
Concentration Gold, Copper , Lead Zinc , Nickel, Zinc, Silver , Tailing Mining treatment , etc.
Chemical Industry :
Alumina Filter cloth , Phosphoric Acid , Phosphate Fertilizer , Pigment , Titanium Pigment , TiO2, Zinc Oxide, Activated carbon, cobalt carbonate, Iron Oxide, Zinc- leads , Titanium Dioxide, pesticides, white carbon black, carbonate calcium , etc.
Food Industry :
Fruite juice,Sugar, Starch, Sweetener, Beer, food oil ,etc.
Environmental protection:
Sewage treatment, slude dewatering, flue gas desulphurization, FGD Filter fabric , Gypum slurry dewatering filtration , salt mud, fly ash, etc.
Specification :
Hangzhou philis filter technology co.,ltd. has grown up to be one of leading manufacturer on dust filtration&spare parts in China.We have imported filter needle felt production line ASSELIN from France and we can produce very good quality non-woven products according customer's requirment.
Based on 8 needle felt production line ,our annual production ability can achieved 20,000 square meters per day . We can produce a large range of various filter fabric, such as polyester filter fabric, Acrylic filter fabric, Fiberglass filter fabric, PPS filter fabric, Nomex ,P84 ,PTFE ,woven filter fabric and so on.
The most important thing is that we introduced German high technology to develop the first filter bag production line in China. Which help most filter bag production factory save a lot of human lab our cost but promote the work effection . The advanced technology and simple operation way of automatic filter bag production line has won a lot of customer's praise.
Q: ,What certifacation you have?
We have got ISO9001 and SGS certification
Q: How long is your delivery time?
A: Generally it is 5-10 working days if the goods are in stock. or it is 15-20 days if the goods are not in stock.It depends on the quantity.Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.Q: What is your terms of payment ?
A: Payment≤1000USD, 100% in advance. Payment≥1000USD, 30% T/T in advance, balance before shippment. Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before deliveryQ: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ; 2. We respect every customer as our friend and we sincerely do business and make friends with them. Q:What should I do if I'm not satisfied with your product?
A:Please contact us as soon as possible and tell us where went wrong.We can only accept refund or exchange if there is any quality issue.
IF you have some interesting please contact us without any hesitate, we will reply you within 24 hours and welcome to have a visit to our factory for more further business and know each other better. We do have the keen interesting to cooperate with you near future.
